Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 37001 |
| Body Style | Rectangular |
| Connection Type | QD Integral |
| Diameter, Body | 30 |
| Housing Material | Thermoplastic |
| Humidity | 90% @ 50 C |
| Indicator | LEDs |
| Input Output | E/M Relay |
| IP Rating | IP67 |
| Light Source | Visible Red LED |
| Material, Lens | Acrylic |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 6 m |
| Mechanical Angle | 15 |
| Minimum Operating Temperature | -40 C |
| NEMA Rating | NEMA 6P |
| Number of Pins | 5 |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -40 C |
| Operation | Dark-ON/Light-ON |
| Output | SPDT Relay |
| Response Time | 15 ms |
| Sensing Mode | Retroreflective Polarized |
| Sensing Range | 6000 |
| Series | |
| Supply Voltage | 90-250 VAC |
| Time, Turn-On Delay | 100 ms |
| Type | Retroreflective Sensors |
Overview
Q45 Series Sensors
The Turck Banner Q45 series of full size photoelectric sensors are an extremely rugged design that exceeds NEMA 6P/ IEC IP67 standards and withstands 1200 psi wash-down. The Q45 series offers opposed, Polarized, Non-polarized retro-reflective, Diffuse, Convergent, Laser and glass or plastic fiber optic sensing modes.
